GORE® Space Cables, ASW (Anti-Static Wire)
Built-up static electricity can threaten space missions when vital interconnects are in danger of short-circuiting. Insulated with a semi-conductive film that effectively drains static electricity, GORE Space Cables, ASW (Anti-Static Wire) are flexible, lightweight additions to Gore’s family of space cables delivering 100% failure-free performance.
联系我们
+1 800 626 7708
Germany
+49 9144 6010
+49 9144 6816 (fax)
UK
+44 1382 56 1511
+44 1382 56 1007 (fax)
Italy
+39 045 6209 209
+39 045 6209 165 (fax)
France
+33 1 5695 6565
+33 1 5695 6401 (fax)
Spain
+34 93 480 6900
+34 93 373 7850 (fax)
Sweden
+46 31 7067800
+46 31 864226 (fax)
China (Beijing)
+86 10 5707 4999
+86 10 5707 4900 (fax)
China (Shanghai)
+86 21 5172 8299
+86 21 6247 9199 (fax)
China (Shenzhen)
+86 755 8359 8262
+86 755 8359 1654 (fax)
South Korea
+82 2 393 3411
+82 2 393 1285 (fax)
Japan
+81 3 6746 2582
+81 3 6746 2571 (fax)
资源中心
Catalog: GORE® Space Cables for Traditional Space Applications
Product Selection Guides, 4.33 MB
Due to operating conditions in space that are the harshest imaginable, space programs must have complete confidence that the cables connected to critical systems will continue to perform under that stress. And because repairs are not easy to make outside of planet Earth, these cables must not only be rugged but also boast decades of proven success. That’s where GORE® Space Cables for Traditional Space Applications from W. L. Gore & Associates come into play.
Overview
As cables move, they create and build up static electricity, which can threaten space missions because of the danger of short circuits in vital interconnects.
Gore now provides an anti-static wire for applications in which cable movements, and other effects, can generate the accumulation of static electric charges. GORE Space Cables, ASW (Anti-Static Wire) have a cable jacket that is insulated with a semi-conductive film to effectively drain static electricity.
Available in diameters from 0.65 to 1.03 mm, our cables are lightweight, flexible and can operate in temperatures from -200° to +200°.
The Science Behind the Cables
The key to our space cables’ performance is the proprietary material used in their insulation, expanded polytetrafluoroethylene (ePTFE). This specialized insulation increases the cable’s ability to bend and flex, while protecting the conductors from stress and damage. The ePTFE material also eliminates the need to trim frayed insulation, and its specialized construction reduces the overall cable diameter so it fits in the tightest enclosures.
Applications
GORE Space Cables, ASW (Anti-Static Wire) are frequently used for:
- stationary plasma thrusters
- yoke applications
- propulsion systems
- cryogenic use
- solar array wiring
- ion thrusters
The cables have been used on many critical space missions, including on several space platforms:
- Eurostar 3000
- LS 1300
- 702 HP
- Star
For more than 25 years, we’ve provided highly reliable cable solutions for the space industry. The 100% success rate of our cables demonstrates our commitment to collaborating with customers when developing reliable and durable cables for these demanding applications.
Features & Benefits
GORE Space Cables, ASW (Anti-Static Wire) feature:
- ePTFE- or engineered fluoropolymer-insulated jacket
- a flexible and lightweight design
- a tight jacket conductivity
These features benefit manufacturers and end users by providing:
- protection against static electricity
- ease of installation due to flexible design
- lower launch mass
- Flat cable concepts, which allow for stackability
Additionally, Gore’s worldwide engineering team provides sales and technical support. If you have any questions about the space cables’ features or benefits, please contact us.
Specifications
GORE Space Cables, ASW (Anti-Static Wire) meet these technical specifications:
| Property | Value |
|---|---|
| Maximum Operating Voltage | 600 V RMS |
| Conductor | Silver-plated copper or copper alloy, true concentric |
| Insulation | GEO: expanded PTFE + polyimide LEO: engineered fluoropolymer |
| Outer Jacket | GEO: semi-conductive film LEO: semi-conductive fluoropolymer |
| Temperature Range | -200°C to +200°C |
For more information about GORE® Space Cables, ASW (Anti-Static Wire), please download the Gore Space Cables Product Portfolio.
Resources
Learn more about GORE Space Cables, ASW (Anti-Static Wire) in thorough data sheets and a white paper discussing the properties of cables that ensure peak electrical performance.
Catalog: GORE® Space Cables for Traditional Space Applications
Product Selection Guides, 4.33 MB
